Powder Metallurgy and Sintering Processes 101: 6 Fascinating Facts.

Posted by Horizon Technology - March 19, 2020

Powder metal technology is actually quite interesting... If you can wade through all the industry lingo and terminology. For a newcomer looking to improve a new or existing component design, the intro to powder metallurgy and the powder metal industry can definitely be confusing and intimidating.

Let’s demystify it. Here are some quick facts to ease your entry into powder metallurgy and sintering processes, including some of the many advantages of powder metallurgy.

6 Facts to Know About Powder Metallurgy and Sintering Processes

1. Powder Metallurgy Is a Green Manufacturing Process

About 97% of the material that enters the powder metallurgy process exits as part of the final product. Good luck finding similar net shape capabilities in any other manufacturing processes. This means very little waste and scrap. Powder metallurgy (PM) is a win-win for your wallet and the environment.

Other metal forming processes, specifically die casting, leave waste behind at multiple stages of manufacturing. Foundries are infamous for creating:

  • Air pollution
  • Liquid pollution
  • Solid waste


2. Compaction Creates a Compact

Powder compaction is an early step in the powder metallurgy process.

It all starts with an alloy of iron powder, a related alloy, or a totally different metal powder. Intense pressure is applied to the powder so it retains the shape of its mold. The resulting component is called a compact.

Properties that influence powder metal compaction include:

  • Particle size
  • Shape
  • Composition
  • Size distribution

The type of powder and how you manufacture it also influences its behavior under pressure.

While it may look like your final product, the compact still needs to undergo sintering to fully fuse the particles together.

powder metallurgy and sintering processes - glass of ice water3. Sintering Does Not Melt the Powdered Metal

The sintering process in powder metallurgy is a form of heat treatment. A conventional sintering process heats up the material to just below its melting point. A precise sintering temperature allows the metals to keep their beneficial properties while fusing them tightly together.

Think of sintering like a glass of ice water. While the ice cubes do melt eventually, they first fuse together at each point of contact.

Click here to learn more about recent breakthroughs in sintering techniques.

4. Density Matters

The denser your component, the better physical properties it has. Density is directly correlated to yield strength, tensile strength, and overall component durability. We also use porosity to indicate component density.

Final product density depends on a few factors:

  • Friction between particles
  • Compaction force
  • Sintering setup
  • Particle size

To achieve the highest performing components, powder metal manufacturers use their expertise to minimize friction between particles and optimize their sintering setup for your materials.

Compaction force depends on the manufacturer’s machinery, and you can control particle size in your specifications.

5. Necking: Not as Odd as It Sounds

Necking is a type of deformation where relatively large amounts of strain localize disproportionately in a specific spot on your powder material. The resulting decrease in the local cross-sectional area becomes the "neck."

When particles fuse like the ice in your glass, the contact points are called necks. As necking between particles grows, the space between the particles (porosity) decreases. As porosity decreases, density increases. In almost all applications, this is a good thing.

Powder metal manufacturers aim to keep the metal particles in the necking state for as long as possible to minimize porosity in the final product.

6. PM Makes a Better Magnet

One of the emerging benefits of powder metallurgy is its ability improve magnetic performance in an electric motor. But you can't just throw any old iron powder into the powder compaction machine and expect results.

Sintered soft magnetic materials and soft magnetic composites are the way forward for rotors, stators, and many other electromagnetic components. These advanced materials offer improved magnetic efficiency vs. electrical lamination steel and other competing methods.

You can learn more about sintered soft magnetics here. (And more about soft magnetic composite via the free e-book below.)

Want More Fun Facts About Powder Metallurgy?

These are only six interesting facts about powder metals. If we tried to collect them all, we’d have to write an entire book. (Actually, we kind of did -- it's below.)

If you have questions about this article, sintering, or anything else powder metallurgy-related, check out our other learning resources. (We're PM Review-approved.)

If you want to dig into more specific powder metal materials, we suggest you start with our favorite branch of materials -- soft magnetic composites: They may just be the key to taking your electric engine design to another level:

ac electric motor efficiency: intro to soft magnetic composite - download e-book here!



(Editor's note: This article was originally published in January 2018 and was recently updated.)
